NON SLAM NON RETURN VALVES(CNR SERIES)
-
NON SLAM CHECK VALVE JIS 20K - 750A
DKC
Range |
Application |
Size |
8”(200A) ~ 120”(3000A) |
Fluid |
Water, Air, Steam, Gas, Sea Water |
Rating |
JIS 10K, 20K, ANSI 150#, 300# PN10, 16, 20 AWWA C 504, KS B 2333
|
End Connection |
Flanged |
Temp. Range |
-50 ~ 600 °C |
Materials |
Body |
A216-WCB, A536 Gr. A351-CF8, A351-CF8M A351-CF3, A351-CF3M B148 C95800 etc.
|
Disc |
A216-WCB, A536 Gr. A351-CF8, A351-CF8M A351-CF3, A351-CF3M B148 C95800 etc. |
Seat |
Rubber (EPDM, BUNA-N etc) Stellite Welding A240-304, A240-316 etc. Rubber Lining |
